KOMPLET Suspended Scaffolding with End Stirrups

KOMPLET Suspended Scaffolding with End Stirrups

The Accesus KOMPLET Suspended Scaffolding with endstirrups is a people and loads lifting equipment. Designed to perform on suspended vertical works on facades, bridges, chimneys, silos, tanks, awnings, and patios.

Aluminum made.

The KOMPLET suspended platform with endstirrups comprises 1, 1.5, 2, or 3 meters long aluminum modules. They can be combined to make 2 to 15 meters long configurations. It can be easily stored, transported, and assembled using screws and bins. Its smallsized parts fit through manholes and difficult to access places of 750mm diameters.

It has a 1.180 kg maximum load capacity. This capacity refers to a 7 meters long KOMPLET, including up to 7 people or tool load and people combined. For more information about length options, load capacity, the maximum number of people allowed on all the possible configurations, please refer to the datasheet.

Ask here for more information

The KOMPLET suspended scaffold with end-stirrups is composed of an aluminum platform,  two lifting devices, and two fall arrest safety systems. There are three different lifting devices options: electric (e.lift® 501 - e.lift® 800), manual (m.lift® 400) or pneumatic (p.lift® 500). The fall arrest safety system is the securichute 600 suspended by steel cables.

Unlimited working height, since it only depends on the passing cable length placed for each job.

Available in three-phase 400V and single-phase 230V version.

Compatible with a wide range of accessories and suspensions that will vary according to the equipment's application.

It is delivered with its corresponding declaration of conformity CE and its use and assembly manual, as required by the 2006/42 European Directive and the EN 1808 standard.

KOMPLET with end stirrups basic features summary table:

Possible modular configurations From 2 to 15 m
Max. load capacity From 170 to 1,180 kg, according to the configuration
KOMPLET weight  From 165 to 555 kg, according to the configuration
Maximum working height Unlimited
Minimum clearance 750 mm diameter
People capacity From 1 to 8, according to the configuration
Lifting speed 9 m/min (available at 18m/min)
Material Aluminum and steel
