BASIC 500 Suspended Scaffolding

The BASIC 500 Suspended Scaffoldings is the reduced-width version of the BASIC Suspended Scaffold Family.

Its removable and lightweight design is intended to provide the best solution for working in places like narrow manholes up to 670 mm in diameters, such as in courtyards or confined spaces.

Like its counterparts from the Accesus Basic family, the Basic 500 was designed for lifting loads and people as required by EN1808 standard.

The Basic 500 cradles or suspended platforms are available in 11 different lengths ranging from 0.8 to 4.8 meters. Their configuration is made by combining standard steel and aluminum modular parts of 0.8, 1.2, and 1.6 meters longThis modularity is the key to the easy and safe assembly, transport, and storage of the Accesus Basic 500 suspended platforms.

Ask here for more information

Depending on the required dimensions and load capacities, it can be configured as a suspended cradle (with a single lift) or as a suspended platform (with two lifts). Its 11 possible configurations are achieved by combining 1, 2, or 3 modules of 0.8, 1.2, or 1.6 m long, 0.64 wide, and 2.28 high. This way, when already passed through a narrow passage, it is possible to assemble a cradle or a suspended platform of up to 4.8 m in length.

Available in two versions: manual (m.lift400) and electric or motorized (e.lift 501) with safety-cable-fall-arrest system. The platform's total width differs between the type of lift installed: 0.88 m with an electric lift or 0.97 m with manual lift. In contrast, the Basic 500 maximum total width with two lifts (manual or electric) is 0.50 meters wide only.

ACCESUS BASIC 500 load, people capacity, and lengths summary table:

Standards and regulations  EN 1808 and Declaration of Comformity CE
Material Steel and Aluminum
Weight From 85 to 290 kg, according to the configuration chosen
Load capacity From 120 to 400 kg and from 1 to 4 people, depending on the configuration chosen
Platform lengths 14 configurations available in 0.4 m sections (from 0.8 to 4.8 m long)



ACCESUS BASIC 500 load, people capacity, and lengths summary table:

Load Table  Quota "A"
0.8 1.2 1.6 2 2.4 2.8 3.2 3.6 4 4.4 4.8
Elevador manual Load capacity  120 240 240 320 320 320 320 400 400 400 400
People capacity  1 2 2 3 3 3 3 4 4 4 4
Elevador manual Load capacity  120 240 240 320 320 320 320 400 400 400 400
People capacity  1 2 2 3 3 3 3 4 4 4 4
Lift total  1 1 ó 2 1 ó 2 1 ó 2 2 2 2 2 2 2 2
