PCP-K Gantry

PCP-K Gantry


The aluminum gantry PCP-K is the most compact and transportable Accesus gantry with a maximum load capacity of 500 kg.

The configurations are not as extensive as those of the PCP-A or PCP-L gantries because it only has five possible beam widths (from 2 to 6 meters) and a single leg height (from 2.1 to 3 meters), adjustable every 200 mm. However, like its brothers PCP-A and PCP-L, the PCP-K is suitable for lifting loads and a maximum of 2 people.

Made mostly of aluminum, the PCP-K is a model that can be easily assembled in a few steps by two people. Certified according to the safety standard EN 795 B.

This model comes with locking swivel wheels suitable for all types of surfaces and terrains, although special wheels can be ordered.


Ask here for more information

Summary table of basic features of the PCP-K gantry:

Maximum load capacity 500 Kg
Weight 52 a 61 Kg
Possible heights 1: K1 (2.100 a 3.000 mm).
Available beam lengths 2 a 6 m
Safety factor for loads 2,1:1
Safety factor for rescuing people 10:1
Suitable for people loading  Máx. 2, según configuración
Material Aluminio
